Shop Drawings
Fabrication-ready drawings for shops and installers: clear dimensions, connection details and material callouts that get approved and built without guesswork.
SCOPE
What is included
Stairs, handrails, guardrails, ladders, gates, canopies and frames.
Beams, columns, base plates, embeds and connection details.
Railings, storefronts, awnings and attachment details.
Fastener and embedment design for the specific substrate.
Drawings adjusted to as-built conditions before fabrication.
Formatted for general contractor and engineer-of-record review.
Projects facts
DELIVERABLES
Fabrication drawings
Erection drawings
Anchorage calculations
Bill of materials
COVERAGE
Miami – Dade, Broward & Palm Beach
SEALED BY
RBG Realiable Builders Group LLC
OFFICE HOURS
Mon – Fri – 9:00 am – 6:00 pm
Precision in every detail
Detailed shop drawings for structural components and miscellaneous metals, prepared to support fabrication, coordination, and permit review.
